Basic Components

MAIN PCB uses Ultra Low Power Microprocessor control to provide a
steady flash rate over the temperature range.

Crystalline Silicon Solar Cells
3 x 6

LS1000+ iiRPM SOLAR ROAD MARKERS

Dimensions and Weight

Size:  ø 6.29” x  1.49”  (ø160 x 38mm)
Weight:  3.4 lbs  (1,250g)

Hybrid  Capacitor                                            2.3V 120F
Number of Hybrid Capacitors                          2PCS

Type:  Steady, Slow Flashing (1/sec), Fast Flashing (3/sec) and Steady/Flashing

FLUSH MOUNT

LS1000+ provides innovative zero
Maintenance lighting safety solutions.

Our LS1000+ models come in five
colors and eight configurations:

COLORS:

Red  -  Yellow  -  Blue  -  White  -  Green

IIRPM CONFIGURATIONS:
- Single Direction for one-way traffic
- Bi-Directional for two-way traffic
- Steady
- Slow Flashing
- Fast Flashing
- Steady / Flashing
- Multiple color configuration

APPLICATIONS:
- In-Roadway Delineation (Dark Highways)
- Wrong-Way Warning
- Stop Sign Warning
- Curve Ahead Warning
- Bike Lanes &Trails Delineation
- Crosswalks
- Median & Roundabout Warning
- Fire Hydrants

- Speed Humps, Traffic Tables

Lighting Properties

Electronic Controller

Physical Properties


Compressive Strength                                            120,000 lbs  (535,000 N)
Water Proof                                                             IP68
Operating Temperture                                             -40°c to +70°c
Operating Time                                                       more than 16 hours
Onset Point                                                             150 - 350 LUX
Charging Time                                                         3hrs (sunny) to 8hrs (Cloudy and Rainy)


LS1000+ CUT SHEET DOWNLOAD

Power Storage

LED

 Model           Colors                  Avg Luminance Intensity (Lux)                     Typical Light Output (mcd)


                       Red                                         44                                                             1500
                       Green                                      64                                                            1475
 LS1000+        Blue                                        21                                                              650
                       Yellow                                     32                                                             1500
                       White                                     133                                                            4769


                                                  Average intensity is measured at the unit

LED Size                                                         3.2mm  x  2.7mm
LED Current                                                    20mA per each
LED Voltage                                                    3V
LED Wattage                                                   3.6 mW
LED Quantities                                                3PCS/6PCS

Aluminum Die Cast Housing         Aluminum A383 Die Cast with Polycarbonate Lenses & Composite Cup

IIRPM

Specifications for Model  :  LS1000+

INTERNALLY ILLUMINATED RAISED PAVEMENT MARKER

OFFICIAL INSTALLER & DISTRIBUTOR OF LED ROAD MARKERS . . . . . . . . . . . . . .

Solar Module Size                                           54mm x 27mm
Solar Maximum Output Power                        3 x 70mA
Solar Voltage                                                   3.15V
